Item

Unit

Value

Working weight

kg

14500

Dimensions

mm

6300*2950*3150

Length of crawler on the ground

mm

3100

Chain pitch

mm

171.45

Track shoe width

mm

600

Min. ground clearance

mm

570

Gradeability

°

25

First gear speed

km/h

0 ~ 2.6

Second gear speed

km/h

0 ~ 4

Crane type

full-turn cable system

Lifting moment

tm

6.4

Max. lifting height

m

8

Rated load capacity

kg

3000

Engine type

Diesel, in-line, 6-cyl, turbocharged

Engine model

QSB8.3-C220

Rated power

kW

162

Rated speed

r/min

2200

Alternator type

UCI274F

Power

kVA

160

Sand blasting equipment type

circular closed type

Pipeline diameter

mm

1422

Blasting guns qty.

pcs.

2

Blasting efficiency (2 guns)

m2/h

11

Blasting width

mm

600

Sand collecting efficiency

%

≥99

Compressor output

m3/min

9.8

Compressor pressure

bar

8

Compressor power

kW

55

Sand collector power

kW

15*2

Sand collector voltage and current

V / A

AC 380 / 50

Max. sand collecting vacuum

kPa

-43

Working radius

m

15

Sand blasting grade

Sa2.5-3

Recommended abrasive material

G25＃ steel shots

Ambient temperature

°C

-15 - +50

Working height (altitude above sea level)

m

3000
