Wheeled welding machines TWM-45/50W
Wheeled paywelders based on the wheeled farm tractors chassis. This model of wheeled tractor chassis can be used in the general condition areas, marsh, desert, loose soil and other harsh environments, complex terrain in the field of large-scale construction operations.
The waterproof electric cabinet is equipped with a digital display of current parameters, ventilation and 380V and 220V external sockets for other construction machines and tools.
Model |
TWM-75/45W | TWM-80/50W | TWM-90/50W | TWM-95/50W |
---|---|---|---|---|
Overall dimensions, mm | 5300*2100*2870 | 5350*2100*2870 | ||
Operating weight, kg | 4700 | 4800 | 4870 | |
Max. speed, km/h | 35.48 | 37.64 | 37.64 | 37.02 |
Max reverse speed, km/h | 16.79 | 17.77 | 17.81 | 17.52 |
Front wheel tread, mm (6 levels, adjustable). | 1672-2003 | 1760-2000 | ||
Rear wheel tread, mm (8 levels, adjustable). | 1712-2112 | 1612-2112 | 1632-2132 | |
Min. ground clearance, mm | 370 | 430 | ||
Generator platform ground clearance, mm | 950 | 1000 | ||
Min. turning radius, m |
5.6 ± 0.3 | |||
Max. traction, kN | 24.7 | 26.4 | 29.7 | 31.3 |
Engine | ||||
Type | Diesel, watercooled, 4 stroke, 4 cylinders in line, direct injection | |||
Rated power, kW/Hp | 55.2 / 75 | 58.8 / 80 | 66.2 / 90 | 70 / 95 |
Rated rotary speed, r/min | 2200 | |||
Generator | ||||
Model | Stamford / Faraday | |||
Output power, Kw | 45 | 50 | 50 | 50 |
Rated frequency, Hz | 50 | |||
Extra socket | 220V-2pcs / 380V-2pcs | |||
Max. weight mass front/rear, kg | 400 / 300 |
